Phoenix Machine Vision Camera

Phoenix

Flexible PoE Camera Module Designed for Easy OEM Integration

Phoenix is a flexible GigE PoE camera module designed for easy OEM integration. It has a hybrid design between a board-level camera and a regular cased machine vision camera. This design allows it to offer a lot of different form factor options. With a wide selection of sensors from 0.4 MP to 20 MP, 4 lens mounts, 3 camera orientations, 3 interface connector options, and cable extension add-ons, the camera can be adapted for various applications.

28 x 28 mm Phoenix Models

ModelsMPResolutionFake FPSFPSSensorFormatPixel SizeShutterLens MountChromaGigE Vision Interface
PHX200S20.0 MP5472 x 3648 px15.6 fpsSony IMX183 CMOS1"2.40 µmRollingC / No MountMono / ColorRJ45 / ix Connector / FFC
PHX124S12.3MP4096 x 3000 px29.0 fpsSony IMX565 CMOS1/1.1"2.74 µmGlobalC / No MountMono / ColorRJ45 / ix Connector / FFC
PHX120S12.3 MP4096 x 3000 px39.0 fpsSony IMX304 CMOS1.1"3.45 µmGlobalC / No MountMono / ColorRJ45 / ix Connector / FFC
PHX089S8.9 MP4096 x 2160 px412.5 fpsSony IMX267 CMOS1"3.45 µmGlobalC / No MountMono / ColorRJ45 / ix Connector / FFC
PHX081S8.1 MP2840 x 2840 px513.8 fpsSony IMX566 CMOS2/3″2.74 µmGlobalC / No MountMono / ColorRJ45 / ix Connector / FFC

24 x 24 mm Phoenix Models

ModelsMPResolutionFake FPSFPSSensorFormatPixel SizeShutterLens MountChromaGigE Vision Interface
PHX122S12.2 MP4024 x 3036 px19.1 fpsSony IMX226 CMOS1/1.7"1.85 µmRollingC / C Ext Head*/ No MountMono / ColorRJ45 / ix Connector / FFC
PHX064S6.3 MP3072 x 2048 px217.7 fpsSony IMX178 CMOS1/1.8”2.40 µmRollingC / C Ext Head / NF / S / No MountMono / ColorRJ45 / ix Connector / FFC
PHX050S1-P/Q5.0 MP2448 x 2048 px422 fpsSony IMX264MZR CMOS
Sony IMX264MYR CMOS
2/3"3.45 µmGlobalC / C Ext Head / NF / No MountPolarized Mono Polarized ColorRJ45 / ix Connector / FFC
PHX050S-P/Q5.0 MP2448 x 2048 px322 fpsSony IMX250MZR CMOS
Sony IMX250MYR CMOS
2/3"3.45 µmGlobalC / C Ext Head / NF / No MountPolarized Mono Polarized ColorRJ45 / ix Connector / FFC
PHX051S5.0 MP2448 x 2048 px422 fpsSony IMX568 CMOS1/1.8″2.74 µmGlobalC / C Ext Head / NF / No MountMono / ColorRJ45 / ix Connector / FFC
PHX050S5.0 MP2448 x 2048 px522 fpsSony IMX264 CMOS2/3"3.45 µmGlobalC / C Ext Head / NF / No MountMono / ColorRJ45 / ix Connector / FFC
PHX032S3.2 MP2048 x 1536 px635.4 fpsSony IMX265 CMOS1/1.8"3.45 µmGlobalC / C Ext Head / NF / S / No MountMono / ColorRJ45 / ix Connector / FFC
PHX023S2.3 MP1920 x 1200 px748.3 fpsSony IMX392 CMOS1/2.3"3.45 µmGlobalC / C Ext Head / NF / S / No MountMono / ColorRJ45 / ix Connector / FFC
PHX016S1.6 MP1440 x 1080 px871.6 fpsSony IMX273 CMOS1/2.9"3.45 µmGlobalC / C Ext Head / NF / S / No MountMono / ColorRJ45 / ix Connector / FFC
PHX004S0.4 MP728 x 544 px9286 fpsSony IMX287 CMOS1/2.9"6.9 µmGlobalC / C Ext Head / NF / S / No MountMono / ColorRJ45 / ix Connector / FFC
Triton Machine Vision Camera

Triton

Factory Tough IP67 Industrial PoE Camera

The Triton camera is built with industrial grade immunity. Lightweight and compact 29 x 29 mm size. Active sensor alignment for superior optical performance. The Triton’s electronics are housed in a sealed two-piece aluminum case secured by 4 M2 screws. The M12 connector for Ethernet and M8 connector for GPIO provides a robust and sturdy connection resistant to shock and vibration. For even more protection, an optional IP67 lens tube can be attached for dust proof and water resistant operation, eliminating the need for an external case. This PoE camera has a wide operating temperature range from -20°C to 55°C ambient. At only 67 grams and 29 x 29 mm, the Triton is an easy fit for reliable operation in any environment. GigE Vision and GenICam compliant PoE machine vision camera designed for all industrial environments.

Area Scan Triton

ModelsMPResolutionFake FPSFPSSensorFormatPixel SizeShutterLens MountChromaInterface
TRI245S24.5 MP5320 x 4600 px14.5 fpsSony IMX540 CMOS4/3"2.74 µmGlobalCMono / ColorM12 GigE Vision
TRI204S20.4 MP4504 x 4504 px25.5 fpsSony IMX541 CMOS1.1"2.74 µmGlobalCMono / ColorM12 GigE Vision
TRI200S20.0 MP5472 x 3648 px35.6 fpsSony IMX183 CMOS1"2.40 µmRollingCMono / ColorM12 GigE Vision
TRI162S16.2 MP5320 x 3032 px46.9 fpsSony IMX542 CMOS1.1"2.74 µmGlobalCMono / ColorM12 GigE Vision
TRI124S12.3MP4096 x 3000 px59.0 fpsSony IMX545 CMOS1/1.1"2.74 µmGlobalCMono / ColorM12 GigE Vision
TRI120S12.3 MP4096 x 3000 px69.0 fpsSony IMX304 CMOS1.1"3.45 µmGlobalCMono / ColorM12 GigE Vision
TRI122S12.2 MP4024 x 3036 px79.1 fpsSony IMX226 CMOS1/1.7"1.85 µmRollingCMono / ColorM12 GigE Vision
TRI089S8.9 MP4096 x 2160 px812.5 fpsSony IMX267 CMOS1"3.45 µmGlobalCMono / ColorM12 GigE Vision
TRI081S8.1 MP2840 x 2840 px913.8 fpsSony IMX546 CMOS2/3″2.74 µmGlobalCMono / ColorM12 GigE Vision
TRI071S7.1 MP3208 x 2200 px1015.8 fpsSony IMX428 CMOS1.1"4.5 µmGlobalCMono / ColorM12 GigE Vision
TRI064S6.3 MP3072 x 2048 px1117.7 fpsSony IMX178 CMOS1/1.8”2.40 µmRollingCMono / ColorM12 GigE Vision
TRI054S 5.4 MP2880 x 1860 px1220.8 fpsSony IMX490 CMOS1/1.55"3.0 µmRollingCColor 24bit HDRM12 GigE Vision
TRI050S1-P/Q 5.0 MP2448 x 2048 px1322 fpsSony IMX264MZR CMOS
Sony IMX264MYR CMOS
2/3"3.45 µmGlobalCPolarized Mono
Polarized Color
M12 GigE Vision
TRI050S-P/Q 5.0 MP2448 x 2048 px1422 fpsSony IMX250MZR CMOS
Sony IMX250MYR CMOS
2/3"3.45 µmGlobalCPolarized Mono
Polarized Color
M12 GigE Vision
TRI051S 5.0 MP2448 x 2048 px1522 fpsSony IMX547 CMOS1/1.8″2.74 µmGlobalCMono / ColorM12 GigE Vision
TRI050S 5.0 MP2448 x 2048 px1622 fpsSony IMX264 CMOS2/3"3.45 µmGlobalCMono / ColorM12 GigE Vision
TRI032S3.2 MP2048 x 1536 px1735.4 fpsSony IMX265 CMOS1/1.8"3.45 µmGlobalCMono / ColorM12 GigE Vision
TRI028S2.8 MP1936 x 1464 px1839.2 fpsSony IMX429 CMOS2/3"4.5 µmGlobalCMono / ColorM12 GigE Vision
TRI023S2.3 MP1920 x 1200 px1948.3 fpsSony IMX392 CMOS1/2.3"3.45 µmGlobalCMono / ColorM12 GigE Vision
TRI016S1.6 MP1440 x 1080 px2071.6 fpsSony IMX273 CMOS1/2.9"3.45 µmGlobalCMono / ColorM12 GigE Vision
TRI005S0.5 MP812 x 620 px21166.4 fpsSony IMX433 CMOS1/1.7"9.0 µmGlobalCMono / ColorM12 GigE Vision
TRI004S0.4 MP728 x 544 px22286 fpsSony IMX287 CMOS1/2.9"6.9 µmGlobalCMono / ColorM12 GigE Vision

Line Scan Triton

ModelsResolutionLine RateSensorSensor SizePixel SizeShutterLens MountChromaInterface
TRI02KA2048 x 1 px60 kHzAMS Dragster DR-2k-714.3 mm7 µmGlobalCMonoM12 GigE Vision

Embedded Vision Triton

ModelsChipsetMPResolutionSensorSensor SizePixel SizeShutterLens MountChromaGigE Interface
Triton EdgeXilinx UltraScale+ ZU3CG MPSoC1.6 MP1440 x 1080 pxSony IMX296 CMOS1/2.9“3.45 µmGlobalCMono / ColorM12
Atlas 5GigE Cameras

Atlas 5GigE

5GBASE-T (5Gbps / 600 MB/s) PoE Camera

Atlas is a GigE Vision and GenICam compliant camera capable of 600 MB/s data transfer rates (5Gbps), allowing for high resolutions and frame rates over standard copper Ethernet cables up to 100 meters. It features a TFL lens mount (M35) that is easily adaptable to F-mount along with C-mount models. All models are active sensor aligned during manufacturing for superior optical performance.  The 5Gbase-T (5GigE) Ethernet interface is 5 times faster than Gigabit Ethernet, 50% faster than USB 3.2 Gen 1×1 and works with regular copper Ethernet cabling. Atlas supports Power over Ethernet (PoE) simplifying integration and reducing cost. It also supports large format APS-C image sensors, up to 31.4MP, without the need for large heatsinks or fans. The 5GigE Atlas hits the sweet spot of faster frame rates, small size and excellent price-performance.

Non-IP67 Models

ModelsMPResolutionFake FPSFPSSensorFormatPixel SizeShutterLens MountChromaGigE Vision Interface
ATL314S31.4 MP6464 x 4852 px117.9 fpsSony IMX342 CMOSAPS-C 27.9mm3.45 µmGlobalTFL (M35 x 0.75) / No MountMono / Color5GBASE-T, M12
ATL196S19.6 MP4416 x 4428 px227.9 fpsSony IMX367 CMOS4/3" 21.7mm3.45 µmGlobalTFL (M35 x 0.75)Mono / Color5GBASE-T, M12
ATL168S16.8 MP5456 x 3076 px332.9 fpsSony IMX387 CMOS4/3" 21.6mm3.45 µmGlobalTFL (M35 x 0.75)Mono / Color5GBASE-T, M12
ATL120S12.3 MP4096 x 3000 px442.5 fpsSony IMX253 CMOS1.1"3.45 µmGlobalC-mountMono / Color5GBASE-T, M12
ATL089S 8.9 MP4096 x 2160 px558.5 fpsSony IMX255 CMOS1"3.45 µmGlobalC-mountMono / Color5GBASE-T, M12
ATL071S7.1 MP3208 x 2200 px674.6 fpsSony IMX420 CMOS1.1"4.5 µmGlobalC-mountMono / Color5GBASE-T, M12
ATL050S5.0 MP2448 x 2048 px798 fpsSony IMX250 CMOS2/3"3.45 µmGlobalC-mountMono / Color5GBASE-T, M12
ATL028S2.8 MP1936 x 1464 px8173 fpsSony IMX421 CMOS2/3"4.5 µmGlobalC-mountMono / Color5GBASE-T, M12
atlas IP67 camera

Atlas 5GigE IP67

5GBASE-T (5Gbps / 600 MB/s) PoE Camera with IP67 Protection

IP67 Models

ModelsMPResolutionFake FPSFPSSensorFormatPixel SizeShutterLens MountChromaGigE Vision InterfaceAvailability:
ATP245S24.5 MP5320 x 4600 px1TBDSony IMX540 CMOS4/3"2.74 µmGlobalC-mountMono / Color5GBASE-T, M12Q1 2022
ATP204S20.4 MP4504 x 4504 px2TBDSony IMX541 CMOS1.1"2.74 µmGlobalC-mountMono / Color5GBASE-T, M12Q1 2022
ATP200S20 MP5472 x 3648 px317.9 fpsSony IMX183 CMOS1"2.40 µmRollingC-mountMono / Color5GBASE-T, M12In Production
ATP162S16.2 MP5320 x 3032 px4TBDSony IMX542 CMOS1.1"2.74 µmGlobalC-mountMono / Color5GBASE-T, M12Q1 2022
ATP124S12.3 MP4096 x 3000 px542.5 fpsSony IMX545 CMOS1/1.1"2.74 µmGlobalC-mountMono / Color5GBASE-T, M12Q1 2022
ATP120S12.3 MP4096 x 3000 px642.5 fpsSony IMX253 CMOS1.1"3.45 µmGlobalC-mountMono / Color5GBASE-T, M12In Production
ATP089S8.9 MP4096 x 2160 px758.5 fpsSony IMX255 CMOS1"3.45 µmGlobalC-mountMono / Color5GBASE-T, M12In Production
ATP081S8.1 MP2840 x 2840 px8TBDSony IMX546 CMOS2/3″2.74 µmGlobalC-mountMono / Color5GBASE-T, M12Q1 2022
ATP071S7.1 MP3208 x 2200 px974.6 fpsSony IMX420 CMOS1.1"4.5 µmGlobalC-mountMono / Color5GBASE-T, M12In Production
ATP051S5.0 MP2448 x 2048 px1098 fpsSony IMX547 CMOS1/1.8″2.74 µmGlobalC-mountMono / Color5GBASE-T, M12Q1 2022
ATP050S5.0 MP2448 x 2048 px1198 fpsSony IMX250 CMOS2/3"3.45 µmGlobalC-mountMono / Color5GBASE-T, M12Q1 2022
ATP028S2.8 MP1936 x 1464 px12173 fpsSony IMX421 CMOS2/3"4.5 µmGlobalC-mountMono / Color5GBASE-T, M12In Production
Atlas SWIR IP67 Machine Vision Camera

Atlas SWIR IP67

Our Atlas SWIR IP67 machine vision cameras feature Sony’s SenSWIR CMOS sensors with built-in IP67 protection for dust proof and water resistant operation. Please note our SWIR models are 1GigE only.

IP67 Models

ModelsMPResolutionFPSSensorSensor SizePixel SizeShutterLens MountChroma / Sensitivity rangeInterface
ATP013S-WC1.3 MP1280 x 1024 px84.9 fpsSony IMX990 CMOS1/2“5 µmGlobalCMono, 400nm to 1700nmM12 GigE Vision
ATP003S-WC0.3 MP640 x 512 px256 fpsSony IMX991 CMOS1/4“5 µmGlobalCMono, 400nm to 1700nmM12 GigE Vision
Atlas10 10GigE 10GBASE-T Machine Vision Camera

Atlas10 10GigE

10GBASE-T (10Gbps / 1.2 GB/s) PoE+ Camera

The Atlas10 machine vision camera features 10 Gigabit Ethernet with Power over Ethernet (PoE) paired with Sony’s 4th generation Pregius-S CMOS sensors. This allows the Atlas10 to reach faster frame rates at high resolutions over a single cable. The 10GigE interface also allows Pregius-S sensors to run at high bit depths (10/12-bit ADC), helping to maximize image quality while still maintaining smooth frame rates. With the option to reduce the region of interest (ROI), along with binning and decimation options, users can unlock even higher frame rates on the Atlas10.

ModelMPResolutionFPSSensorFormatPixel SizeShutterLens MountChromaInterface
ATX470S47.0 MP8240 x 5628 px22.5 fpsSony IMX492 CMOS1.4"2.315 µmRollingTFL (M35 x 0.75)Mono / Color10GBASE-T, M12
ATX245S24.5 MP5320 x 4600 px45.4 fpsSony IMX530 CMOS4/3"2.74 µmGlobalTFL / C-MountMono / Color10GBASE-T, M12
ATX204S20.4 MP4504 x 4504 px54.1 fpsSony IMX531 CMOS1.1"2.74 µmGlobalC-MountMono / Color10GBASE-T, M12
ATX162S16.2 MP5320 x 3032 px76.1 fpsSony IMX532 CMOS1.1"2.74 µmGlobalC-MountMono / Color10GBASE-T, M12
ATX124S12.3 MP4096 x 3000 px89.7 fpsSony IMX535 CMOS1/1.1″2.74 µmGlobalC-MountMono / Color10GBASE-T, M12
ATX081S8.1 MP2840 x 2840 px136.7 fpsSony IMX536 CMOS2/3″2.74 µmGlobalC-MountMono / Color10GBASE-T, M12
ATX051S5.0 MP2448 x 2048 px205 fpsSony IMX537 CMOS1/1.82.74 µmGlobalC-MountMono / Color10GBASE-T, M12
Helios2 3D Camera Time of Flight

Helios 3D Time-of-Flight Camera

The Next Generation of Time of Flight

The Helios2 ToF camera is engineered for high performance operation in industrial environments. Built for demanding 24/7 environments and a variety of industrial 3D applications such as robotics, 3D inspection, and logistics, including advanced material handling, pick and place, sorting, palletization / de-palletization, volume estimation, and more.

 Helios2+Helios2Helios
Sensor: Sony IMX556PLR Sony IMX556PLR Sony IMX556PLR
Resolution: 640 x 480 px, 0.3 MP 640 x 480 px, 0.3 MP 640 x 480 px, 0.3 MP
VCSEL Wavelength 850 nm, Indoors 850 nm, Indoors 850 nm, Indoors
Working Distance: 0.3 - 8.3 m (Normal, HDR)
      0.3 - 2.5 m (High-Speed)
0.3 - 8.3 m 0.3 - 6.0 m
Precision (Depth Noise) @ 1 m: 0.6 mm 0.6 mm1.6 mm
Accuracy up to 1.5 m± 4.0 mm± 4.0 mm± 5.0 mm
Lens Field of View: 69° x 51° 69° x 51° 59° x 45°
# of Operating Distance Modes: 6 Modes (Normal)
      5 Modes (HDR)
      3 Modes (High-Speed)
6 Modes2 Modes
# of Pixel Formats: 10 88
High Dynamic Range (HDR) Mode? Yes NoNo
High-Speed Mode? Yes NoNo
Adjustable Starting Distance Point for Modes: Yes Yes No
Dimensions:60 x 60 x 77.5 mm60 x 60 x 77.5 mm 55 x 55 x 77.5 mm
Weight398 g398 g 254 g
Frame Rate: 30 FPS (Normal)
      10 FPS (HDR)
      103FPS (High-speed)
30 FPS (All Distance Modes)30FPS (Near Mode) , 15FPS (Far Mode)
Exposure Presets: HDR, Manual: 332
IP67 Case: Yes YesNo
Power over Ethernet (PoE): Yes Yes No
"Flying Pixel" Filter: Yes Yes No
Indoor Ambient Light Filter: On-Camera & On-Sensor On-Camera & On-Sensor On-Sensor Only
Combine with other Helios Cameras? Yes Yes Yes
Combine with Color Camera for RGB Point Cloud? Yes Yes Yes
