Broadcom 2-CH 10G/1G RDMA Host Channel Adapter (HCA) Network Card

The PCIE-10GETH2-BC (Broadcom® BCM957416A4160C) is a dual-port 10GBASE-T, PCIe 3.0 x8 Host Channel Adapter (HCA) that supports RDMA (RoCEv2), UDP, and TCP 10GigE data transfers with the Atlas10 10GigE camera. This network card is fully compliant with the IEEE 802.3an standard and uses the Broadcom BCM57416 Ethernet controller with the integrated dual-channel 10GBASE-T transceiver. Important: This RDMA HCA is not NBASE-T compatible and does NOT support 5GigE or 2.5GigE speeds. You will need to use GPIO external power to run your Atlas10 camera as this adapter does not support Power over Ethernet (PoE).

Specifications

Manufacturer #:	Ports:
Broadcom BCM957416A4160C	2 x 10GBASE-T IEEE 802.3an / 1000BASE-T IEEE 802.3ab
Other specifications and features:
• x8 PCI Express v3.0 compliant • RDMA over Converged Ethernet (RoCEv2) • SR-IOV with up to 128 VFs • Function Level Reset (FLR) support • TruFlow™ flow processing engine • Virtual Network Termination–VXLAN, NVGRE, Geneve, GRE encap/decap • vSwitch acceleration • Tunnel-aware stateless offloads • DCB support: PFC, ETS, QCN, DCBx • SMBus 2.0 • MCTP over SMBus • PCIe-based UART and KCS • Jumbo frames up to 9 KB • Advanced Congestion Avoidance	•Multiqueue, NetQueue, and VMQ • IPv4 and IPv6 offloads • TCP, UDP, and IP checksum offloads • Large Send Offload (LSO) • Large Receive Offload (LRO) • TCP Segmentation Offload (TSO) • Receive-side Scaling (RSS) • Transmit-side Scaling (TSS) • VLAN insertion/removal • Interrupt coalescing • Network boot-PXE, UEFI • iSCSI boot • MSI and MSI-X • Conforms to the PCI Express Card Electromechanical Specification Rev. 3.0
Package includes:
1 x 2 Port Broadcom 10GigE RDMA HCA, 1 x low profile bracket

USD $275.00

SKU: PCIE-10GETH2-BC Category: Interface Cards, PoE & Power Supply
